Name: 100KW AC 3 Phase Resistive Load Bank Continuous Working For Emergency Use
Brand: KINGWAY
Price: 4948 USD

Brand Name : KINGWAY

Model Number : KLB-100

Certification : CE,ISO,ROHS

Place of Origin : CHINA

MOQ : 1 UNIT

Price : 4948-5250USD

Payment Terms : L/C, T/T, Western Union

Supply Ability : 4000 UNITS PER YEAR

Delivery Time : 50 Working Days

Packaging Details : Wooden Carton

Product Name : Kingway Resistive Load Bank

Rated Volage : 400V

Frequency : 50HZ

Max Load Power : 800KW

Power Factor : 0.8

Communication Interface : RS232/RS485

Contact Now

Kingway 100KW Resistive Load Bank for emergency use

A load bank is a piece of electrical test equipment used to simulate an electrical load, to test an electric power source without

connecting it to its normal operating load. During testing, adjustment, calibration, or verification procedures, a load bank is

connected to the output of a power source, such as an electric generator, battery, servo amplifier or photovoltaic system, in

place of its usual load.

Kingway load bank are designed for both portable and permanently installed applications and can confidently withstand everyday

use in a demanding industrial or rental environment, testing range10-5000KW .

Technical Parameters
Rated voltage / frequency				AC 3-phase 4 wire 400V/50Hz
Maximum load power				Resistive load: 100kW
Load Resolution				Resistive load: 8 Steps, 1, 2, 2, 5, 10, 20, 20, 50kW
Power Factor				1
Load accuracy (per Step)				±5%
Load accuracy (Whole Load bank )				±3%
Display accuracy				Level 0.5
Control Power				External power 380VAC 3 phase 4 wire 50Hz
Wire Connection				Load bank input——busbar (star coupling “Y”) Control power input——terminal block
Communication Interface				RS232/RS485
Insulation				F
Way of Working				Continuous Working
Cooling				Forced air, horizontal air intake and upwards exhaust cooling
Transportation				With lifting eyes and wheel castors
Color				As customer’s requirements or as our design
Dimensions				960(L)1060(W)1400(H)
Weight				350KGS
Ambient Temperature				-10°C～+50°C
Relative Humidity				≤95%
Altitude				≤2500m
Atmospheric Pressure				86～106kPa
Contactor				Schneider
Fuse				MIRO
PLC				Siemens
Light Button				ABB
Relay				OMRON
Alloy Resistor				Kingway
Data Processing Software				Kingway
